Product Overview
The NEO COM NEO-1016PF2G1F 16-Port 10/100Mbps PoE Switch is a high-performance unmanaged network solution designed for businesses, IP surveillance systems, wireless deployment, and enterprise-grade connectivity. It features 16 PoE ports, along with 2 Gigabit RJ45 uplinks and 1 SFP fiber uplink, allowing fast data transfer, long-distance connections, and flexible installation. This switch follows the IEEE 802.3af/at PoE standard, delivering up to 30W per port and a total PoE power budget of 150W, making it ideal for powering IP cameras, VoIP phones, wireless APs, and access control devices.
The switch includes AI Mode, VLAN Mode, and Extend Mode, enabling long-range PoE delivery up to 250 meters and isolated communication to prevent broadcast storms. With 6kV surge protection, fangless thermal design, and wide temperature tolerance, the NEO-1016PF2G1F is engineered for durability in harsh environments. Easy rack-mount installation, smart power management, and stable switching performance make it a reliable, cost-effective solution for modern network infrastructures.
Key Features
- 16× 10/100Mbps PoE ports.
- 2× Gigabit RJ45 uplink ports.
- 1× 1.25Gbps SFP uplink port.
- IEEE 802.3af/at PoE compliant.
- Auto 10/100/1000Mbps MDI/MDIX support.
- PoE power budget up to 150W.
- Extend mode supports up to 250m transmission.
- VLAN mode prevents broadcast storm issues.
- AI watchdog auto-reboot for frozen devices.
- 6kV surge protection on all PoE ports.
- Fanless silent operation.
- Rack-mount design for easy installation.
- LED indicators for status monitoring.
- Ideal for IP camera, VoIP, and Wi-Fi AP deployment.
Applications
- IP CCTV surveillance networks.
- Small and medium business networking.
- Wireless access point deployment.
- VoIP phone systems.
- Access control systems.
- Smart home or building automation.
- Retail and commercial networking.
- Industrial and outdoor edge networks.
Hardware Specifications
- PoE Port: 16*10/100/1000Mbps PoE Port.
- SFP: Single-fiber/Dual-fiber supported. Distance varies in the module.
- ESD Protection: Contact Discharge 6KVDC, Air Discharge 8KVDC.
- ESD Protection: Contact discharge 6KV DC, air discharge 8KV DC.
- Surge Protection: Differential mode ±2KV, common mode ±4KV.
- Thermal Fan: Fanless design.
- Installation: Rack mount.
Installation Notes
- Ensure stable AC 100–240V power input
- Mount the switch securely on a rack or wall
- Use high-quality Ethernet cables for PoE devices
- Insert the SFP module properly before powering on
- Keep proper ventilation around the device
- Avoid moisture or direct exposure to chemicals
- Enable VLAN mode for isolated camera networks
- Use Extend mode for long-range PoE installations
- Monitor LED indicators to verify connectivity
Environmental / Operating Conditions
Operating temperature: –20°C to 55°C
Storage temperature: –30°C to 75°C
Operating humidity: 10%–90% (non-condensing)
Storage humidity: 5%–95% (non-condensing)
Surge protection: Differential ±2kV, Common ±4kV
ESD protection: 6kV contact, 8kV air
Global Availability
The NEO COM NEO-1016PF2G1F PoE Switch is available across international markets through authorized distributors, IT retailers, and online technology outlets. It is supplied in Asia, Europe, the Middle East, and Africa, ensuring wide compatibility for global installation standards. With manufacturer-backed reliability, PoE compliance, and strong demand in surveillance and wireless networking sectors, the device is widely accessible for enterprise, industrial, and commercial deployment.
