NEO COM S/M86 86-inch 4K Ultra HD Interactive Smart Display Android Windows Infrared Touch 8 Mic Array 48MP Camera Wi-Fi Bluetooth

Product Overview

The NEO COM S/M86 is a professional 86-inch 4K Ultra HD interactive smart display designed for classrooms, corporate boardrooms, training centers, and collaborative workspaces. Featuring a 16:9 aspect ratio, 5000:1 contrast ratio, and 350 cd/㎡ brightness, it delivers vibrant colors, sharp visuals, and clear details. Its 89° viewing angles ensure content is visible from every corner of the room, making it perfect for large spaces.

Powered by Android 11/12 OS (optional) and a T982/311D chipset, the S/M86 enables smooth multitasking, fast app execution, and responsive touch interactions. The 20-point infrared touch panel (capacitive optional) allows precise annotations, gestures, and collaborative activities.

Optional Windows 10/11/12 slot-in PC support provides full desktop functionality alongside Android apps. Equipped with dual 10W speakers, an 8-mic array, and a 48MP camera (optional wide-angle), it offers immersive audio-visual experiences for video conferencing, presentations, and online learning. With a lifespan of ≥50,000 hours, the S/M86 ensures reliable performance over extended use.

Key Features

• 86-inch 4K Ultra HD Display with optional 2K resolution.
• High Brightness & Contrast: 350 cd/㎡, 5000:1 contrast ratio.
• Wide Viewing Angle: 89° for consistent clarity.
• Infrared Touch: 20-point panel (capacitive optional) for interactive collaboration.
• High Performance: T982/311D chipset, 3GB RAM (expandable to 4GB), 32GB ROM (expandable to 128GB).
• Connectivity: USB2.0/USB3.0 x2, HDMI, VGA, RJ45, audio, DC input.
• Wireless Integration: Dual-band Wi-Fi 2.4G/5G, Bluetooth 4.2/5.0.
• Audio & Video: Dual 10W speakers, 8-mic array, 48MP camera (optional).
• Optional Windows Slot-In PC: i3/i5/i7 processors, up to 16GB RAM, up to 2TB storage.
• Durable & Customizable: Silver/Black or custom colors with extended warranty options.
• Optional Accessories: Floor stand, projector, smart pen, stylus.
• Energy Efficient: Standby ≤0.5W, input voltage 110–240V 50/60Hz.

Applications

• Large corporate boardrooms for meetings and presentations.
• Universities and classrooms for interactive lessons and collaborative learning.
• Training centers and workshops for real-time collaboration.
• Public spaces for digital signage and information display.
• Retail and hospitality environments for interactive engagement.
• Command and monitoring centers for data visualization and operations.

Installation & Setup (Step-by-Step)

• Unpack the display and check included accessories: wall mount kit, stylus x2, remote, power cord, manual.
• Choose an installation location with optimal height and viewing distance.
• Mount the display using VESA-standard wall mount or optional floor stand.
• Connect power and switch on the display.
• Connect via Wi-Fi (2.4G/5G) or LAN (RJ45).
• Boot Android 11/12 or optional Windows slot-in PC.
• Calibrate the touch panel for accurate response if required.
• Install software or applications for education, business, or signage.
• Test speakers, 8-mic array, and camera for conferencing or presentations.
• Verify connectivity and peripherals before regular operation.

Environmental & Operating Conditions

• Power Consumption: 400W.
• Standby: ≤0.5W.
• Input Voltage: 110–240V, 50/60Hz.
• Temperature & Humidity: Suitable for standard indoor environments.
• Lifespan: ≥50,000 hours.
• Noise Level: Near-silent operation.
• Thermal Management: Built-in cooling ensures reliable performance.

Global Availability

The NEO COM S/M86 is available worldwide with multilingual OS support, extended warranty options, and customizable configurations. Its dual OS support, universal connectivity, and optional accessories make it ideal for global classrooms, corporate offices, training centers, public spaces, and commercial applications, delivering professional-grade interactive display performance anywhere.
